Noker Portable Air Conditioner Dc To Ac 12v 110v 220v 3000w Pure Sine Wave Portable Inverter Power Supply

Short Description:

FSA-H serial is a full power high quality reliable off-grid pure sine wave DC-AC isolated inverter. Its main functions include:Digital design controlled by double inlet single chip microcomputer, new circuit with anti-interference and fast response to adapt to load changes, high reliability, high quality fan with low noise, -40℃ ~ +50℃ wide working temperature, complete protection function and so on.

Suitable for residential, commercial, ships, cars, trailers, mines, construction sites and remote areas without power grid facilities, the output can be used for fans, TV, radio, induction cooker, air conditioning, power tools, outdoor camping equipment, communication equipment, notebook computers, lighting, etc.

Send email to us

Product Detail

Product Tags

Features

1. A 3% distortion rate for pure sine wave output;
2. A wide work range of -40°C to +50°C;
3. The work mode for intelligent fan cooling;
4. Support optional CANBUS and RS485 connectivity;
5. Incorrect input connection, high or low voltage, output overload, short circuit, or overheating, etc.;

6. Wireless remote control or wired remote control and so on(optional);
7. Input voltage and frequency can be selected by DIP S.W;
8. DC input and AC output are completely isolated;
9. Suitable for lead acid battery and lithium battery;

Specification

Model		FSA500H	FSA1000H	FSA1200H	FSA1500H	FSA2000H
Output	Continuous Power	500 Watt	1000 Watt	1200 Watt	1500 Watt	2000 Watt
	Peak Power	1000 Watt	2000 Watt	2400 Watt	3000 Watt	4000 Watt
	Output Waveform	Pure Sine Wave(Distortion rate≤3%)
	Output Frequency	50/60Hz±2%
	Output Voltage	Default Setting: 230V±5V		Default Setting: 110V±5V
		Other Voltage: 230V/240V		Other Voltage: 110V/120V
Input	Input Voltage	12VDC	24VDC	12VDC	24VDC
	Input Voltage Rate	DC9.5V-15.5V	DC19V-31.5V	DC9.5V-15.5V	DC19V-31.5V
	Low Voltage Alarm	DC10.5V±0.5V	DC21V±0.5V	DC10.5V±0.5V	DC21V±0.5V
	Low Voltage Protection	DC9.5±0.5V	DC19±0.5V	DC9.5±0.5V	DC19±0.5V
	Low Voltage Recovery	DC12V±0.5V	DC24.5V±0.5V	DC12V±0.5V	DC24.5V±0.5V
	Over Voltage Recovery	DC15V±0.5V	DC30.5V±0.5V	DC15V±0.5V	DC30.5V±0.5V
	Over Voltage Protection	DC15.5V±0.5V	DC31.5V±0.5V	DC15.5V±0.5V	DC31.5V±0.5V
Output Protection	Over Temperature Protection	70℃±5℃
		Protection mode: re-start after buzzer continuously alarm 5 sounds with turning off the output voltage and temperature lower than 65 degrees.
	Output Short Circuit	Protection mode: restore the output after turn off the output voltage and exclude the possibility of short circuit.
	Overload Protection	The load at 105-115% lasts for 180 seconds, and at 115-150% for 10 seconds
		Protection mode: restore the output after the buzzer continuous alarm with turned off output and lower load
Conversion Efficiency		92% (Full load)
Wireless remote control		50m Barrier-free control inverter
RS-485		RS-485 communication
CANBUS		CANBUS communication
TTL		TTL communication
No-load Current		≤0.3A (DC12V)
Working Temperature		〔-20℃〕TO〔＋50℃〕
Working Humidity		20-90%RH Non-condensing
Storage Temperature		〔-30℃〕TO〔＋70℃〕
Cooling Mode		Intelligent temperature control air cooling, or fan start-up when temperature > 100W
Certificate		CE、FCC and ROHS
